Main features

1.The machine is specilized for slot-alu insulating glass. Alu-spacing frame is coated and placed between two piece of glass.
2.Roll pressure makes insulating glass sealed and thickness accurate.

Technical Parameters

Brand name                       MAG Machine

Model                                  LY1500

Power voltage:                  3P/380V/ 50Hz ( Optional: 3P/220V/60Hz )

Total power:                      0.75 KW

Process width:                   ≤1500mm

Process thickness:           ≤40mm

Glass carry speed:            1-5m/min

Overall dimmension         2000*2000*1200(mm)

Weight                                1000kg
