1.Main features
1). The machine applies to processing glass bead;
2). it adopts two saw blades which cut off and chamfer angle for glass
bead at the same time.
3). The machine motor is horizontally fixed.
4). It has characteristics of easy operation, stability, and high efficiency.
2.Technical Parameters
Brand Name |
MAG |
Model |
SYJW03-1800 |
Power voltage |
380V 50HZ or Customer specification |
Input power |
1.5KW |
Air pressure |
0.4~0.6MPa |
Air consumption |
80L/min |
Main motor rotation speed |
2800r/min |
Saw cutting width |
100mm |
Cutting length |
320-1800mm |
Cutting Height |
29mm |
Overall dimension |
1900mm×700mm×1350mm |
Weight |
210kg |
