1.Main features
1). Used for mullion
cutting
2). One time two V shape cutting
3). Patent technology to prevern collapese cutting precedur.
4). Pneumatic clamping
5). Easily adjustable deepth, and adjustable stable feeding speed.
5). Automatic crossing cutting two mullion end in one time. Save profile cost
and improve efficiency. Support arm ensure cutting precision.
6). Special clamping device ensure safety operation. Friendly using stopper for
easily measuring.
2.Technical Parameters
Brand Name |
MAG |
Model |
SVJ-65 |
Power Supply |
380V 50Hz or customers specifications |
Input power |
2*0.75KW |
Air pressure |
0.4~0.6MPa |
Air consumption |
80L/min |
Main motor rotation speed |
2800r/min |
Saw cutting width |
120mm |
Cutting height |
90mm |
Cutting length |
300-1600mm |
Overall dimension |
1900*700*1350mm |
Weight |
300kg |
