1.Main features

1). High quality carbide tipped saw blades.
2). Automatic material feeding system.
3). Adjustable clamping system in front, back, up and down direction.
4). One time clamping, no need other operation.
5). Spraying cooling system.
6). safety protection system.

2.Technical Parameters

Brand Name                                                 MAG                                                                         MAG
Model                                                            LJJB-450*100                                                         LJJB-500*140
Power Supply                                               380V 50Hz or customers specifications
Input power                                                 2.2kw                                                                       2.2kw
Air pressure                                                  0.5-0.8Mpa                                                            0.5-0.8Mpa
Air consumption                                          200L /min                                                                200L /min
Main motor rotation speed                      2840r/min                                                               2840r/min
Saw blade dimension:                                Φ450xΦ30                                                             Φ500×Φ30
Saw Cutting (W x H)                                   120*200mm                                                           300x120mm
Feeding length                                             5-120mm                                                                5-140mm
Repeat locating length                              ≤0.1mm                                                                   ≤0.1mm
Angle cutting tolerance                            ±5′                                                                             ±5′
Plane of cutting surface                            ≤0.10                                                                        ≤0.10
Cutting profile surface roughness           Ra12.5μm                                                               Ra12.5μm
Overall dimension                                       1240*1300*1300mm                                          5500x1300x1300mm
Weight                                                           500Kg                                                                       540Kg
