1.Main features

1). CNC system is equipped. High quality imported hard alloy saw blades.
2). Automatic material feeding system.
3). Adjustable clamping system in front, back, up and down direction.
4). Safe and reliable cutting.
5). Spraying cooling system
6). Can be added digital-control system or digital-display system.
7). Japanese imported saw blade.

2.Technical Parameters

Brand Name                                                MAG
Model                                                            LJJAS-500
Power Supply                                               380V 50Hz or customers specifications
Main motor power:                                   3kw
Main motor rotation speed:                    2840r/min
Saw blade dimension:                                Φ500×Φ30
Feeding length                                            5-700mm
Saw Cutting (W x H)                                   135x300mm
Repeat locating length                             ≤0.1mm
Angle cutting tolerance                            ±5′
Plane of cutting surface                            ≤0.10
Cutting profile surface roughness           Ra12.5μm
Overall dimension                                       2340x1400x1200mm
Weight:                                                         800Kg
