1.Main features

1).It has features of easy operation,reliable performance,advanced technique and convenient maintenance etc.
2). Used for corner connector of aluminum profiles cutting.
3). Only one time clamping,can achieve 6 meters corner section bar continous cutting.
4). Equipped with inches and millimeters ruler options.
5). Spraying cooling system
6). Imported carbide saw blade is of accurate processing and high efficiency.

7).feed motion using linear motion bearing small movement resistance of high precision.

8). Feeding mechanism of automatic feeding system is stable and reliable with high efficiency.

9).Working clamping,cutting and uses the pneumatic control system,convenient operation,safety and reliability,high productivity.

2.Technical Parameters

Brand Name                                                     MAG
Model                                                                LJJA-500
Power Supply                                                   380V 50Hz or customers specifications
Main motor power                                         3.0kw
Main motor rotation speed:                        2840r/min
Saw blade dimension:                                    Φ500×Φ30
Saw Cutting (W x H)                                       135*300mm
Feeding length                                                 5-500mm
Repeat locating length                                  ≤0.1mm
Angle cutting tolerance                                ±5′
Plane of cutting surface                                ≤0.10
Cutting profile surface roughness               Ra12.5μm
Overall dimension                                           2340*1400*1200mm
Weight:                                                             510Kg
