Main Features:

1. To solve the problem of four edges can't grinding small piece of glass.

2. Can pour security Angle, reduce the security hidden danger

3. The work environment without dust, equipped with continuous water supply pump, stainless steel water tank.

Technical Parameters:

1. Ac power: AC380V 50 hz or Customized

2. Brand Name: MAG Machine

3. The total power: 1.5 KW

4. The grinding of glass thickness: 1.5 mm above

5. The maximum size of grinding glass: L1500 * W1500mm

6. The minimum size of grinding glass: L240*W240mm

7. Abrasive belt linear velocity: 14 m/s

8. Belt Model: L2000 * W80mm *100P

9. Machine Dimension: L600 * W620 * H1450mm

10. Operation table size: L2200 * W1200 * H900mm

11. Total Weight: 150KG
