1.Main features

1). High quality carbide tipped sawblades.
2). High precision main shaft to keep sawbades running stability.
3). Pneumatic-hydraulic damp device to keep the stable feeding.
4). Adopt high quality guide railing system in the feeding system.
5). HIgh precision linear bearing to keep the repositioning precision.
6). Auto turnable machine head.
7). Vertical and horizontal clamping cylinder.
8). Spraying cooling system.
9). Right head feeding adopts high helical pitch ball screw-lead motion, with high accurate driving, locating and smooth working.
10). Adopt CNC technique, can achieve various profiles auto cutting off.

2.Technical Parameters

Brand Name                                      MAG                                 MAG                                  MAG
Model                                                  LJZ2-500x4200               LJZ2X-500 x4200             LJZ2S-500 x4200
Power Supply                                     380V 50Hz or customers specifications
Main motor power:                         2*2.2kw                           2*2.2kw                            5.9kw
Air pressure                                       0.5-0.8MPa                     0.5-0.8MPa                      0.5-0.8Mpa
Air consumption                               200L /min                        200L /min                         200L /min
Rotation speed                                 2840 r/min                      2840 r/min                       2840 r/min
Max Cutting length                          400-4200mm                  400-4200mm                   435-4200mm
Saw blade dimension:                     500x30x4.4xZ120          500x30x4.4xZ120           500x30x4.4xZ120
Cutting angle:                                   -45 ° -67.5 ° 90 °             -45 ° -67.5 ° 90 °             -45 ° -67.5 ° 90 °
Repeat locating length                   ≤0.3mm                           ≤0.3mm                            ≤0.2mm
Angle cutting tolerance                  ±5′                                     ±5′                                      ±5′
Plane of cutting surface                  ≤0.10                                ≤0.10                                 ≤0.10
Cutting Surface roughness             Ra12.5µm                       Ra12.5µm                        Ra12.5µm
Cutting W x H(mm)                          135x300/135x200         135x300/135x200   135x300/135x200
Overall dimension (WxHxL)            5700x1650x1520           57500x1650x1950         5700x1650x1950
Weight                                                1400kg                             1500Kg                              2000Kg
