1.Main features

1). High quality carbide tipped saw blades.
2). High precision main shaft to keep saw blades running stability.
3). Pneumatic-hydraulic damp device to keep the stable feeding.
4). Adopt high quality guide railing system in the feeding system.
5). High precision linear bearing to keep the repositioning precision.
6). Auto turnable machine head.
7). Vertical and horizontal clamping cylinder.
8). Spraying cooling system.
9). Safety protection system, heavy duty unibody steel construction.
10). CNC system CAN put in, it can make the cutting much more precise, and the operating more visualized.

2.Technical Parameters

Brand Name                                                     MAG
Model                                                                LJZ2X-500*4200
Power Supply                                                   380V 50Hz or customers specifications
Main motor power:                                        2.2kw*2
Air pressure                                                      0.5-0.8M pa
Air consumption                                              200L /min
Main motor rotation speed:                        2840r/min
Min/max Cutting length                                400-4200mm
Saw blade dimension:                                    Φ500×Φ30
Cutting angle:                                                  -45 ° 90 ° -67.5 °
Cutting W x H                                                   135x200mm
Repeat locating length                                  ≤0.3mm
Angle cutting tolerance                                ±5′
Plane of cutting surface                                ≤0.10
Cutting profile surface roughness               Ra12.5μm
Size: (width × high × long)                             5530mm × 1650mm × 1950mm
Weight:                                                             1500Kg
