1.Main features

1).  Adopt PA control system with clear interface and easy operating.
2). With professional windows and doors CAM software, according to the settings, the fixture automatically placed automatically move to achieve high-efficiency three- dimensional four-axis processing.
3). CAD graphics can be directly input into the system, and can also directly draw graphics on the system CAD platform, generate NC files, edit and implement processing programs.
4). Single positioning and double positioning design, up-load and down-load profile non-stop machine, with higher processing efficiency.
5). Centralized lubrication using intermittent supply system, the tool cooling used to the spray pump cooling device by system control.
6). Can be processed aluminum, aluminum-wood composite profiles, copper and other light metal processing.
7). One time clamping, multi-faceted profile to complete drilling, tapping, chamfering, milling slot and shaped hole processing.
8). The magazine capacity is two groups of 16 knives, one for the servo disc magazine with 8T and the other for the straight magazine with 8T.
9). The head adopts fully enclosed safety structure to ensure the safety of operators.

2.Technical Parameters

Brand Name                                                            MAG
Model                                                                        LM4-CNC-6000
Power Supply                                                           380V 50Hz or customers specifications
Power:                                                                      16KW
Electrical main spindle power                             9.5KW
Air pressure                                                             0.6-0.8Mpa
Rotation speed:                                                      18000-24000 RPM
Maximum output torque of the spindle           6.4NM
Tool Magazine                                                        8+8
Tool holder                                                               ISO30
Max. length                                                             100mm
Fixtures number                                                     8 sets
Processing journey                                                 X axis: 6000mm; Y Axis: 500mm; Z Axis: 300mm
Feeding speed                                                         X axis: 50m/min, Y Axis: 25m/Min; Z axis: 10m/min;
Working range                                                        6000X500X300
Overall dimension                                                  9000mmx2230mmx3060mm
Weight:                                                                     6200Kg
